Grade V
Pre-filter

Grade A
Precision filter

Grade B
Super-fine filter

Grade C
Activated Carbon

For the removal of particles about 2μm.

Water separating efficiency: ≥95%

Residual oil content :≤2PPM

Intial differential pressure:0.01MPa

For the removal of particles above 1μm.

Resdual oil content: ≤0.1PPM

Initial differential pressure:0.01MPa

For the removal of particles above 0.01μm.

Resdual oil content : ≤0.01PPM

Initial differential pressure: 0.012MPa

For the removal of oil vapor and hydrocarbon.

Resdual oil content : ≤0.003PPM

Intial differential pressure: 0.02MPa

Element change: After runs 10000h

Flow rate
m3/min

Dia. mm

Height
mm

Weight
KGS

Element
P/N

Element
QTY
